Copper conductor PVC insulated and sheathed fat cable

  • Dirigent: Solid or stranded copper conductor
  • Isolierung: PVC (Polyvinylchlorid)
  • Hülle: PVC (Polyvinylchlorid)
  • Nennspannung: 300/500 V
  • Standard: JB/T 8734

 Sparen Sie durchschnittlich mindestens 30%

BVVB
  • Symbol

    Produktbeschreibung

    BVVB: Product Description and Specifications

Bezeichnet als Type BVVB (Flat Cable), this specification comprises parallel-laid Class 1 Solid Copper Conductors insulated and sheathed with PVC. Rated for 300/500V, the flat geometric profile is engineered specifically for direct surface mounting (nail-in clips) and plaster-depth installation where circular cables are dimensionally restrictive.

  • Symbol

    Vorteile

    BVVB: Benefits and Features

  • Flat Profile (Space-Saving) Parallel core arrangement allows flush mounting on walls, minimizing protrusion depth compared to round cables.

  • Rigid Class 1 Conductor Solid copper structure provides mechanical self-support, ensuring straight runs between clips without sagging.

  • Double Insulation PVC Sheath over PVC Insulation offers dual-layer protection against impact for exposed surface wiring.

  • 300/500 V-Bewertung Optimized for domestic fixed wiring (Sockets/Lighting) and renovation projects without conduits.

Abmessungen/Parameter

ModellSpezifikationCa. OD (mm)Ca. Kabelgewicht (kg/km)
BVVB2x1.06.4047.74
BVVB3x1.08.7068.82
BVVB2x1.57.3064.05
BVVB3x1.510.0593.30
BVVB2x2.58.6895.21
BVVB3x2.512.02139.44
  • Symbol

    Produktionsprozesse von Elektrokabeln

Unsere Produktion setzt auf modernste Fertigungsausrüstung, um eine überlegene Kabelleistung zu gewährleisten Der Prozess integriert Präzision Kupferziehen und Glühen Mit fortgeschrittenen Isolationsstrang Technologie für gleichmäßige Dicke, strenge Qualitätskontrolle während der gesamten Produktion, einschließlich Online-Funkenprüfung und automatisierte Durchmesserüberwachung Dieser strenge Arbeitsablauf garantiert, dass unsere Elektrokabel streng sind. IEC- und GB-Standards Für Wohn - und Industrienutzung.

Produktionsprozesse von Photovoltaikdraht

Verpackung für den Versand

Um den verschiedenen Transportanforderungen gerecht zu werden, können viele Verpackungsmethoden verwendet werden.

Stromkabelpackung

Haben Sie noch mehr Fragen?

Beginnen Sie ganz einfach damit, Antworten auf häufig gestellte Fragen zu unserem Unternehmen und unseren Dienstleistungen zu finden.

F: Produktbezeichnung?

A: Copper Core PVC/PVC Flat Cable.

  • Standard: JB/T 8734.2.

  • Struktur: Parallel-laid cores (Non-twisted).

  • Int'l Äquivalent: Similar to 6242Y (Twin & Earth) in BS 6004.

Q: BVVB vs. RVV?

A: Geometry & Flexibility.

  • BVVB: Flat & Rigid (Class 1). Designed for surface mounting (Nail-in clips).


  • RVV: Round & Flexible (Class 5). Designed for mobile appliances and extension cords.

F: Primäre Anwendungen?

A: Surface Wiring (Retrofit).

  • Walls/Ceilings without conduits.

  • Under-plaster installation (Shallow depth).

  • Linear lighting / Power sockets.

Q:Purpose of Flat Profile?

A: Installation Efficiency.

  • Flush Mounting: Reduced cable depth minimizes protrusion from wall surfaces.

  • Thermal: Parallel core arrangement prevents heat buildup common in bundled round cables.

F: Spannungsbewertung?

A: 300/500V. (Suitable for single-phase domestic circuits).

F: Outdoor-Eignung?

A: Nein. Standard White/Grey PVC sheath is UV-stabilisiert nicht. Long-term exposure leads to embrittlement. Indoor use only.

Q: Available Configurations?

A: Specs:

  • Cross-section: 0.75mm² to 10mm².

  • Kerne: 2-Core / 3-Core.

Q : Conductor Material?

A: Standard: Oxygen-Free Copper (OFC).

  • Compliance: IEC 60228 Class 1 (Solid) or Class 2 (Stranded).

  • (Note: CCA available only for custom non-standard orders).
