RV Cable
Single-core non-sheathed cable with flexible conductor for general purposes
Conductor: Class 5 Flexible Conductor (consisting of multiple fine copper wires twisted together).
Insulation: PVC (Polyvinyl Chloride).
- Sheath: None (This is a single-core, non-sheathed cable).
- Standard: Meets IEC 60228 requirements for flexibility.
- Fast Sample Processing with Customized Solutions
- High-Quality Materials
- Affordable Price Options
- Global Delivery
- For better data protection, make sure that all uploads are secure
Save at least 30% on average
-
Product Description
RV Cable: Product Description and Specifications
Type RV constitutes a flexible single-core building wire utilizing Fine Stranded Copper (Class 5). Rated for 70°C operation, the PVC-insulated assembly meets IEC 60227 requirements. Voltage classification: 300/500V (Small Gauge) and 450/750V (Power Gauge). Primary use: Internal cabinet wiring and connection points requiring high flexibility (bending radius).
-
Advantages
RV Cable : Benefits and Features
Class 5 High Flexibility Fine stranded copper structure (IEC 60228) enables tight bending radii, perfect for complex cabinet wiring and moving parts.
Dual Voltage Rating Categorized for safety: 300/500V (H05V-K) for instrument control; 450/750V (H07V-K) for power distribution.
Certified Compliance Fully meets IEC 60227 and GB/T 5023 standards. PVC insulation provides verified resistance to oils, acids, and abrasion.
Dimensions/Parameters
| Model | Specification | Approx. OD (mm) | Approx. Cable Weight (kg/km) |
|---|---|---|---|
| RV | 1x0.5 | 2.10 | 8.58 |
| RV | 1x0.75 | 2.30 | 11.31 |
| RV | 1x1.0 | 2.40 | 13.38 |
| Model | Specification | Approx. OD (mm) | Approx. Cable Weight (kg/km) |
|---|---|---|---|
| RV | 1x1.5 | 2.90 | 19.58 |
| RV | 1x2.5 | 3.50 | 30.41 |
| RV | 1x4.0 | 4.10 | 45.50 |
| RV | 1x6.0 | 4.60 | 62.85 |
| RV | 1x10 | 6.00 | 109.09 |
| RV | 1x16 | 7.10 | 164.49 |
| RV | 1x25 | 8.70 | 255.03 |
| RV | 1x35 | 9.90 | 345.97 |
| RV | 1x50 | 11.7 | 491.08 |
| RV | 1x70 | 14.0 | 684.97 |
| RV | 1x95 | 15.6 | 908.48 |
-
Production Processes Of Electrical Cable
Our production relies on state-of-the-art manufacturing equipment to ensure superior cable performance. The process integrates precision copper drawing and annealing with advanced insulation extrusion technology for uniform thickness. Throughout production, strict quality control measures—including online spark testing and automated diameter monitoring—are applied to every meter. This rigorous workflow guarantees that our electrical cables meet stringent IEC and GB standards for residential and industrial use.
Packing For Shipment
To meet various transportation needs, there are many methods of packaging that can be used.
Have more questions?
Q: Product Definition?
A: Flexible Single-Core Cable.
Conductor: Class 5 Fine Stranded Copper.
Insulation: PVC.
Sheath: None.
Int’l Equivalent: H07V-K (450/750V) / H05V-K (300/500V).
Q: RV vs. BVR?
A: Flexibility Level (Conductor Class).
RV: Class 5. Very fine strands (e.g., 0.25mm). High flexibility for cabinet doors/moving parts.
BVR: Class 2. Coarse strands. Semi-rigid. For fixed conduit wiring only.
Q: Voltage Classification?
A: Size Dependent.
< 1.5mm²: 300/500V (Instrument/Control).
≥ 1.5mm²: 450/750V (Power Distribution).
Q:Manufacturing Standards?
A: Dual Compliance.
IEC: 60227-3.
GB: GB/T 5023.3.
Test Standard: GB/T 18380.12 (Flame Retardancy).
Q: Conductor Specifications?
A: Annealed Copper (Class 5).
Material: 99.99% Oxygen-Free Copper (OFC).
Structure: Multi-strand concentric fine wire (High vibration resistance).
Q: Installation Scenarios?
A: Confined Spaces.
Switchgear / Control Panels.
Curved Raceways.
Dynamic connections (vibrating machinery).
Q: Outdoor Rating?
A: No. Standard PVC insulation is sensitive to UV radiation. Indoor use only unless installed in light-proof conduits.
Q : Max Operating Temperature?
A: 70°C. (Long-term continuous operation).
