RHH
600V/2000V XLPE Insulated Single Conductor for Dry Locations (UL 44)
Voltage Rating 600V / 2000V
Insulation Material XLPE Thermoset. High heat resistance (90°C Dry) & physical durability.
Conductor Options
Copper: Soft Annealed (ASTM B3/B8)
Aluminum: 8000 Series Alloy (ASTM B800/B801)
Compliance Standards UL Listed. Complies with UL 44, ICEA S-95-658, and RoHS-2.
- Fast Sample Processing with Customized Solutions
- High-Quality Materials
- Affordable Price Options
- Global Delivery
- For better data protection, make sure that all uploads are secure
Save at least 30% on average
-
Product Description
RHH : Product Description and Specifications
Designated for industrial raceways and conduits, the RHH series features premium Cross-Linked Polyethylene (XLPE) insulation rated for continuous operation at 90°C in Dry Locations. Available with Soft Annealed Copper or 8000 Series Aluminum Alloy conductors (ASTM B800/B801), this cable supports voltage ratings of 600V and 2000V. It serves as the definitive specification for general-purpose wiring in recognized raceways, ensuring full compliance with UL 44 and ASTM standards.
-
Advantages
RHH : Benefits and Features
Thermal Rating 90°C Continuous Operation (Dry). Supports Emergency Overload up to 130°C.
Installation Capabilities Approved for Conduits, Ducts, Troughs, and Aerial Systems (Messenger Supported).
Structural Integrity XLPE Thermoset Insulation. Resists deformation under high thermal stress and physical load.
Conduit Optimization Class B Compressed/Compact Stranding. Reduced Outer Diameter (OD) maximizes conduit fill ratio.
Dimensions/Parameters
| Conductor Size (AWG/kcmil) | Conductor Stranding | Diameter Over Conductor (inch) | Diameter Over Conductor (mm) | Insulation Thickness (mils) | Insulation Thickness (mm) | Approx. OD (inch) | Approx. OD (mm) | Copper Weight (kg/km) | Approx. Weight (Copper) (kg/km) |
|---|---|---|---|---|---|---|---|---|---|
| 8 | 7 | 0.0486 | 1.23 | 60 | 1.52 | 0.256 | 6.5 | 75 | 109 |
| 6 | 7 | 0.0612 | 1.55 | 60 | 1.52 | 0.287 | 7.3 | 119 | 158 |
| 4 | 7 | 0.0772 | 1.96 | 60 | 1.52 | 0.335 | 8.5 | 191 | 238 |
| 2 | 7 | 0.0974 | 2.47 | 60 | 1.52 | 0.382 | 9.7 | 304 | 358 |
| 1 | 19 | 0.0664 | 1.69 | 80 | 2.03 | 0.457 | 11.6 | 386 | 472 |
| 1/0 | 19 | 0.0745 | 1.89 | 80 | 2.03 | 0.492 | 12.5 | 483 | 577 |
| 2/0 | 19 | 0.0837 | 2.13 | 80 | 2.03 | 0.535 | 13.6 | 614 | 718 |
| 3/0 | 19 | 0.0940 | 2.39 | 80 | 2.03 | 0.579 | 14.7 | 773 | 886 |
| 4/0 | 19 | 0.1055 | 2.68 | 80 | 2.03 | 0.630 | 16.0 | 973 | 1097 |
| 250 | 37 | 0.0822 | 2.09 | 95 | 2.41 | 0.709 | 18.0 | 1152 | 1317 |
| 300 | 37 | 0.0900 | 2.29 | 95 | 2.41 | 0.760 | 19.3 | 1383 | 1563 |
| 350 | 37 | 0.0972 | 2.47 | 95 | 2.41 | 0.803 | 20.4 | 1609 | 1799 |
| 400 | 37 | 0.1040 | 2.64 | 95 | 2.41 | 0.846 | 21.5 | 1838 | 2041 |
| 500 | 37 | 0.1159 | 2.94 | 95 | 2.41 | 0.921 | 23.4 | 2280 | 2503 |
| 600 | 61 | 0.0992 | 2.52 | 110 | 2.79 | 1.024 | 26.0 | 2762 | 3045 |
| 750 | 61 | 0.1109 | 2.82 | 110 | 2.79 | 1.118 | 28.4 | 3459 | 3770 |
| 1000 | 61 | 0.1280 | 3.25 | 110 | 2.79 | 1.256 | 31.9 | 4594 | 4949 |
-
Production Processes Of UL cable
JOCA produces UL wires using a fully automated workflow. The cycle synchronizes copper drawing and stranding with precise PVC or XLPE extrusion. Instead of waiting for post-production checks, we employ continuous inline monitoring—using laser diameter gauges and spark testers to catch defects instantly. For multi-core variants, the line handles cabling, shielding, and jacketing to exact specifications. Before shipping, every batch faces final electrical and mechanical inspections to verify full compliance with UL standards.
Packing For Shipment
To meet various transportation needs, there are many methods of packaging that can be used.
Have more questions?
Q: Product Definition (RHH)?
A: Rubber High-Heat. Thermoset-insulated single conductor cable rated for 90°C in Dry Locations. Complies with UL 44.
Q: Wet Location Capability?
A: Restricted. Standard RHH is for Dry Locations Only. (Note: For wet environments, please select our dual-rated RHH/RHW-2 or USE-2 models).
Q:Voltage Ratings?
A: 600V / 2000V. Available in standard 600V and high-voltage 2000V ratings for heavy industrial loads.
Q: Conductor Options?
A: Copper & Aluminum Alloy.
Copper: Soft Annealed (ASTM B3/B8).
Aluminum: 8000 Series Alloy (ASTM B800/B801). Compact stranded for weight reduction.
Q: RHH vs. RHW-2?
A: Environmental Rating.
RHH: 90°C (Dry Only). Flame retardant.
RHW-2: 90°C (Wet & Dry). Superior moisture resistance.
Q: Direct Burial Application?
A: Prohibited for Standard RHH. RHH is designed for Conduits & Raceways. For underground trenching, specify USE-2 rating.
Q: Oil & Sunlight Resistance?
A: Optional Specs. Standard XLPE provides basic chemical resistance. “Sunlight Resistant” or “Oil Res I/II” jackets available upon request (Check cable print).
Q : Certification Documents?
A: UL Listed. Manufactured in strict compliance with UL 44. Mill Test Reports (MTR) and UL certification files available for project submittals.
